For BMW F48 Android Screen Apple CarPlay Car Audio Multimedia Player

BMW X1 Android10 /13 Car Stereo Display Replacement Upgrade Retrofit

Short Description:

* It is a direct display upgrade for BMW X1 F48 NBT and EVO with original OEM 8.8inch screen,no need reprogramming or coding and cutting cables.

* Retain original radio functions after screen replace, such as radio , Bluetooth, rear view camera, radar , 360 cameras, steering wheel control, iDrive knob control, etc.

* Smooth two systems work on car and easy switching between android system and original system.

* Big touchscreen enhance car video performance and enjoy your way.

* 4G LTE or Wifi network,

* Bluetooth handfree call,

* GPS Navigation,

* Music and Video playing.

* Android 10：

Wireless Carplay

Wired Android Auto through USB

* Android 13：

Wireless & Wired Apply Carplay

Wireless & Wired Android Auto, Support Phone Link

Send email to us

Features

Specification

Video

Product Tags

It is specially made for BMW X1 F48 2015-2017 NBT system , X1 2018-2021 EVO system with 6pin LVDS.

BMW X1 F48 ( 2015-2017) NBT.

BMW X1 F48 ( 2018-2022) EVO.

10.25inch or 12.3inch screen fit both LHD and RHD BMW X1 F48.

10.25inch HD IPS LCD screen (resolution: 1280*480 or 1920*720) or 12.3inch HD IPS LCD screen ( resolution: 1920*720).

E84 CIC AUX switching mode is manual usually, F48 NBT AUX switching mode is Automatic usually .

Support split screen and PIP: Multi-tasking run 2 apps at the same time, picture in picture.

Keep original BMW F48 system features such as factory radio, GPS navigation, Bluetooth, DVD/CD,USB,SD, etc,
support factory rear view camera reverse trajectory. 360 camera, door open warning, be compatible with original iDrive knob control
and steering wheel control, be compatible with original sound system and optic fiber, play lossless audio.

Android system functions include Android navigation, touch screen, android music and video, android Bluetooth call and Bluetooth music, USB port, SD card, android apps installation.

Built in GPS with rapid positioning and navigation support google map and waze etc.

Multi menu languages for choice：English, German，Spanish, Korean，Italian, Dutch, Russian, French, Portuguese, Japanese, Hebrew, Thai, Greek

Previous: For BMW F10 F07 5 series Android Screen Apple CarPlay GPS Navigation System

Next: For BMW F15 F16 Android Screen Apple CarPlay Car Audio Multimedia Player

Specification 1 (Real Android13)
1	CPU	Qualcomm Snapdragon 662(SM6115) /665(SM6125) Octa core 11nm LPP
1	CPU	4 * A73 (2.0Ghz) + 4 * A53 (1.8Ghz)
2	GPU	Adreno 610 (950Mhz)
3	OS	Android 13
4	RAM ROM	4+64GB/ 8+128GB/ 8+256GB EMCP chip eMMC5.1/UFS2.1+LPDDR4X
5	Screen&Resolution	10.25inch IPS LCD G+G Touch Screen 1280480 /1920720
5	Screen&Resolution	12.3inch IPS G+G Touch HD Screen 1920*720
6	Bluetooth	Bluetooth 5.0+ BR/EDR+BLE.
7	WiFi	IEEE 802.11 2.4G b/g/n 5G a/g/n/ac.
8	4G SIM	LTE Category 4：4DL Down 150Mbps 5UL Up 75Mbps
9	Video	Support 4K HD video, H.264 (AVC)，H.265 (HEVC)
10	Image	OpenGL ES 3.1+,OpenCL2.0
11	Carplay	Wireless & Wired Apply Carplay, Wireless & Wired Android Auto, Support Phone Link
11	Carplay	Wireless and Wired Phone Mirroring
12	Camera	AHD CCD Reverse Camera
13	GPS	GPS/Beidou/Glonass,support built in or on-line maps
14	Extend Memory	Support Micro TF card slot, USB port. 128M max
15	Suppot	Real Time Weather ;Ota (on-line upgrade)
16	Optional	360 Panoramic View Camera optional

Specification 2 (Android10)
1	CPU	Qualcomm snapdragon M501A (MSM8953) 14nm LPP Cortex-A53 64
1	CPU	Octa core 1.8GHz.
2	GPU	Adreno 506 (650MHz)
3	OS	Android 10
4	RAM ROM	4GB +64GB, eMMC5.1+LPDDR3
5	Screen&Resolution	10.25inch IPS LCD G+G Touch Screen 1280480 /1920720
5	Screen&Resolution	12.3inch IPS G+G Touch HD Screen 1920*720
6	Bluetooth	BT4.1+ BR/EDR+BLE
7	WiFi	IEEE 802.11; 2.4G b/g/n ;5G a/g/n/ac
8	4G SIM	LTE Cat 7 Down 300Mbps Up 100Mbps
9	Video	Support 4K HD video, H.264 (AVC)，H.265 (HEVC)
10	Image	OpenGL ES 3.1+,OpenCL2.0
11	Carplay	Wireless Carplay, Wired Android Auto through USB
12	Camera	AHD CCD Camera
13	GPS	GPS/Beidou/Glonass,support built in or on-line maps
14	Extend Memory	Support Micro TF card slot, USB port. 128M max
