Mercedes Benz W246 Android Display Autoradio CarPlay

Mercedes Benz B class Android10/13 Autoradio Screen Upgrade Retrofit

Short Description:

Ugode Android Screen Display Special for Mercedes Benz B class W246 (2012-2017)  NTG4.5 NTG4.7 NTG5.0 NTG5.1 system

* Mercedes Benz B Class W246 big android screen replacement with original small OEM one, direct upgrade without reprogramming coding and cutting.

* Original stereo features will be retained after installation.

* Two systems operation on android, keep original NTG radio.

* Enjoy your way with big screen and multiple functions.

* Support Video Support 4K HD video, H.264 (AVC),H.265 (HEVC)

* Wifi or 4G LTE network

* Original Bluetooth and android Bluetooth for calling handfree, music play

* Support AHD CCD rearview camera (original camera and aftermarket camera and 360 camera)

* Keep original GPS navigation, android GPS navigation support online and offline maps: google map waze etc

*  Android 10:

  Wireless Carplay

  Wired Android Auto through USB

*  Android 13:

  Wireless & Wired Apply Carplay

  Wireless & Wired Android Auto, Support Phone Link


Features

Specification

Product Tags

It is specially made for Mercedes Benz B Class W246 (NTG4.5/4.7 or NTG5.0/5.1/5.2)

For Mercedes Benz B class W246 2012-2017:

B160 B180 B200 B220 CDI

Mercedes Benz B class (NTG4.5/4.7):

B160 B180 B200 B220 CDI (2012-2015)

Mercedes Benz B class  (NTG5):

B160 B180 B200 B220 CDI (2016-2017)

Mercedes Benz B class screen need to check LHD or RHD before order, both 10.25inch or 12.3inch display can fit B class ,
but LHD and RHD Mercedes Benz display has different bracket mount .

Support split screen and PIP: Multi-tasking run 2 apps at the same time, picture in picture.

Keep original NTG radio system features such as factory radio, GPS navigation, Bluetooth, DVD/CD,USB,SD, etc,
support factory rear view camera reverse trajectory. 360 camera, door open warning, be compatible with original iDrive knob control
and steering wheel control, be compatible with original sound system and optic fiber, play lossless audio.

Android system functions include Android navigation, touch screen, android music and video, android Bluetooth call and Bluetooth music, USB port, SD card, android apps installation.

Built-in A2DP, Hands-free calling,Transfer phonebook with alphabetic name search, Caller record, Call history.

Support common video and audio formats: MP4, AVI, MKV, WMV, MOV, FLV and MP3, WMA, AAC, FLAC, APE, WAV other common formats.

Built in GPS with rapid positioning and navigation support google map and waze etc.

Q:  How to check if car radio is NTG4.5/4.7 or NTG5.0/5.1/5.2 ?

A: There is two kinds of android screen hardware for Mercedes Benz A CLA GLA, that is NTG4 and NTG5 system.
Please check the radio menu to judge if it is NTG4 or NTG5.

Q:  If Mercedes Benz B class has no AUX input, how to make sound coming out?

A:  Android screen can activate Aux on NTG4.5 4.7 radio system for sound,  NTG5.0 5.1 5.2 has no AUX input ,
only USB input, NTG5 android screen come with USB-AUX audio adaptor.

Q: If there is sound delay on B class NTG5 screen upgrade , that is sound not sync with video playing after installation. how to solve it?

A: In such case, it is some brands of original headunit which has sound delay with android screen, need to install a DSP amplifier directly for sound delay solution. we have it for sales also.

Q: AUX switching mode is Manual or Automatic?

A: NTG4.5/5.0 has both Manual and Automatic AUX switching mode.


  • Previous:
  • Next:

  • Specification 1 (Real Android13)
    1 CPU Qualcomm Snapdragon 662(SM6115) /665(SM6125) Octa core 11nm LPP
     4 * A73 (2.0Ghz) + 4 * A53 (1.8Ghz)
    2 GPU Adreno 610 (950Mhz)
    3 OS Android 13
    4 RAM ROM 4+64GB/ 8+128GB/ 8+256GB EMCP chip eMMC5.1/UFS2.1+LPDDR4X
    5 Screen&Resolution 10.25inch IPS LCD G+G Touch Screen  1280*480 /1920*720
    12.3inch IPS G+G Touch HD Screen 1920*720
    6 Bluetooth  Bluetooth 5.0+ BR/EDR+BLE.
    7 WiFi IEEE 802.11 2.4G b/g/n 5G a/g/n/ac.
    8 4G SIM  LTE Category 44DL Down 150Mbps 5UL Up 75Mbps
    9 Video Support 4K HD video, H.264 (AVC)H.265 (HEVC)
    10 Image OpenGL ES 3.1+,OpenCL2.0
    11 Carplay

    Wireless & Wired Apply Carplay, Wireless & Wired Android Auto, Support Phone Link

    Wireless and Wired  Phone Mirroring
    12 Camera AHD CCD Reverse Camera
    13 GPS GPS/Beidou/Glonass,support built in or on-line maps
    14 Extend Memory Support Micro TF card slot, USB port. 128M max
    15 Suppot Real Time Weather ;Ota (on-line upgrade)
    16 Optional  360 Panoramic View Camera optional

    Specification 2  (Android10)
    1 CPU Qualcomm snapdragon M501A (MSM8953) 14nm LPP Cortex-A53 64
    Octa core 1.8GHz.
    2 GPU Adreno 506 (650MHz)
    3 OS Android 10
    4 RAM ROM 4GB +64GB, eMMC5.1+LPDDR3
    5 Screen&Resolution 10.25inch IPS LCD G+G Touch Screen  1280*480 /1920*720
    12.3inch IPS G+G Touch HD Screen 1920*720
    6 Bluetooth  BT4.1+ BR/EDR+BLE
    7 WiFi IEEE 802.11; 2.4G b/g/n  ;5G a/g/n/ac
    8 4G SIM LTE Cat 7 Down 300Mbps Up 100Mbps
    9 Video Support 4K HD video, H.264 (AVC)H.265 (HEVC)
    10 Image OpenGL ES 3.1+,OpenCL2.0
    11 Carplay

    Wireless Carplay, Wired Android Auto through USB

    12 Camera AHD CCD Camera
    13 GPS GPS/Beidou/Glonass,support built in or on-line maps
    14 Extend Memory Support Micro TF card slot, USB port. 128M max
