Q:

Hi Ugode Team,

Hope you are well.

I am interested in purchasing your 10.25-inch Android screen for my 2013 Audi RS4 B8.5 Avant.

My car is a right-hand-drive Japanese import fitted with:

MMI 3G+ / HN+
Factory Bang & Olufsen audio
Factory reversing camera
Front and rear parking sensors
Audi Drive Select
Factory Bluetooth and microphone (Bluetooth calls but NO Bluetooth Streaming A2DP)
I am considering the 10.25-inch RHD anti-glare HIGH version with 8GB RAM and 128GB storage.

Apologies for the number of questions, but I would like to confirm the specification and compatibility before ordering.

Could you please confirm:

Is this version fully compatible with a Japanese-market, right-hand-drive RS4 B8.5 with MMI 3G+?
Will the original MMI menus, Drive Select, steering-wheel controls, B&O audio, parking sensors and factory reversing camera continue to work?
Can you guarantee that the unit supplied will have the Snapdragon 665 processor, 8GB RAM, 128GB storage and a native 1920 × 720 display?
Could you send me a photograph of the current unit’s About Device page showing the processor, RAM, storage, Android version and MCU version?
How is CarPlay and Android audio connected to the factory B&O system? Does it use the AMI/AUX input, and is the required adaptor included?
Can the original Audi Bluetooth system and factory microphone remain in use for telephone calls? Will the microphone work through android auto auto/car play calls too?
Does the screen have a physical HDMI video output?
I have also seen the digital instrument cluster for the Audi A4/A5/Q5 on your website which I would also like to purchase at the same time.

Could you therefore confirm:

Can your 10.25-inch Android screen be connected to your digital dashboard so that it displays or mirrors Google Maps, Waze, CarPlay and other screen content?
Does the digital dashboard have a physical HDMI input, or does it communicate with the Android screen by another method?
Can the centre screen and digital dashboard operate independently, or do they only show the same image?
Do you offer an RS4-specific dashboard configuration with:
A tachometer scale suitable for the RS4’s 8,250rpm redline
A 9,000rpm or 10,000rpm display with the correct shift point graphics
MPH as the main speed display
S-tronic gear indication
RS4 graphics and suitable shift-warning points?
I would not want the generic 8,000rpm A4/A5 version, as this would not be suitable for the RS4 engine.

My factory reversing-camera quality is also quite poor. Could you confirm whether the Android screen supports an upgraded AHD 1080p boot-handle camera, and whether dynamic steering guidelines and the original parking-sensor graphics can be retained? I would keep the OEM camera in the short term.

Finally, please could you provide:

The price for the 10.25-inch RHD anti-glare 8GB/128GB screen
The price for the correct RS4 digital dashboard
The price for a compatible upgraded AHD camera
Any package discount available when purchasing these items together
Shipping cost to Rochdale, United Kingdom, postcode OL12 0QS
The current production and delivery timeframe
Whether UK VAT and import charges are included or collected separately on delivery
Details of the warranty and return process
I attach a few photos

Many thanks

A:

Thank you very much for your detailed message and for your interest in our products.

We have checked your vehicle information. For your 2013 Audi RS4 B8.5 Avant RHD Japanese import with MMI 3G+ (HN+), our 10.25-inch Android screen (RHD version, Anti-glare High version, 8GB RAM + 128GB storage) is the correct version.

Regarding your questions:

1. OEM functions compatibility

The Android screen is designed to work together with the original Audi system. The following functions can be retained:

Original MMI system and menu access
Steering wheel controls
Bang & Olufsen factory audio system
Factory reversing camera
Parking sensor display
Audi Drive Select

The installation keeps the original MMI system, and you can switch between the Android system and the original Audi interface.

2. Hardware specification

The current high version uses:

Qualcomm Snapdragon 665 processor
8GB RAM
128GB storage
Native 1920 × 720 resolution display

We can provide you with a photo of the current unit’s About Device page before shipment for confirmation.

4. HDMI output

The Android screen itself does not provide a physical HDMI video output.

5. Digital dashboard

Our Audi digital dashboard is compatible with A4/A5/Q5 B8 platforms.

The digital dashboard works as an independent display system. It does not simply mirror the Android screen like an external monitor.

For functions such as:

Google Maps
Waze
CarPlay navigation display

“USB-to-HDMI is unstable and not recommended. Currently, there is no alternative method for Android to communicate with the digital instrument cluster.”

Regarding the RS4-specific design:

The standard version is mainly designed for A4/A5/Q5 models. We need to confirm whether a specific RS4 layout is available before making a final recommendation.

Please send us your preferred dashboard style, and we can check with our technical team.

6. Reverse camera upgrade

Yes, our Android screen supports an upgraded AHD 1080P camera.

The upgraded camera can provide a much clearer image compared with the original camera.

Regarding:

Dynamic steering guidelines
Original parking sensor graphics

the compatibility depends on the original vehicle system and camera configuration. Since you already have the OEM camera, we recommend keeping it initially and upgrading only if you need better image quality.

Pricing & shipping

For the exact quotation, we will confirm based on your final configuration:

10.25-inch RHD Anti-glare High version (8GB/128GB)
Audi digital dashboard
AHD 1080P camera

We can also offer a package price when purchasing multiple items together.

Shipping:

Delivery to the UK is available.
Shipping time is usually around 3–7 working days after dispatch.
Import VAT/duties depend on the shipping method and UK customs policy. We will confirm the details before shipment.

 Warranty:

We provide warranty support for our products.
If any issue occurs, our technical team will assist with troubleshooting and replacement parts if required.

We have received your attached photos and will check them carefully. We will reply with the final recommendation and quotation after confirmation.

Thank you again for your detailed information. It really helps us provide the correct solution for your RS4.

Best regards,
UGODE Team
